SketchUp是相当简便易学的强大工具,一些不熟悉电脑的建筑师可以很快的掌握它,它融合了铅笔画的优美与自然笔触,可以迅速地建构、显示、编辑三维建筑模型,用户在操作的时候,需要使用快捷键,那么sketchup常用的快捷键有哪些?下面,小编就来跟大伙介绍sketchup常用的快捷键。
sketchup一款功能强大的3D绘图软件,因此有很多人会去下载使用它。但是有时候为了提高工作效率,一直用鼠标点击指令图标会使工作效率变慢很多。我们可能就需要记住一些快捷键了,那么草图大师都有哪些快捷键呢?下面,小编就来跟大家分享sketchup常用的快捷键。
sketchup常用的快捷键有哪些
Sketchup快捷键:
编辑/撤销 Ctrl+z 编辑/放弃选择 Ctrl+t
编辑/辅助线/删除 Alt+E 编辑/辅助线/显示 Shift+ Q
编辑/辅助线/隐藏 Q 编辑/复制 Ctrl+C
编辑/剪切 Ctrl+X 编辑/全选 Ctrl+A
编辑/群组 G 编辑/删除 Delete
编辑/显示/全部 Shift+A 编辑/显示/上一次 Shift+L
编辑/显示/选择物体 Shift+H 编辑/隐藏 H
编辑/粘贴 Ctrl+V 编辑/制作组建 Alt+G
编辑/重复 Ctrl+Y 编辑/将面翻转 Alt+V
编辑/炸开/解除群组 Shift+G 查看/工具栏/标准 Ctrl+1
快捷键电脑图解-1
查看/工具栏/绘图 Ctrl+2 查看/工具栏/视图 Ctrl+3
查看/工具栏/图层 Shift+W 查看/工具栏/相机 Ctrl+4
查看/显示剖面 Alt+, 查看/显示剖切 Alt+.
查看/虚显隐藏物体 Alt+H 查看/页面/创建 Alt+A
查看/页面/更新 Alt+U 查看/页面/幻灯演示 Alt+Space
查看/页面/删除 Alt+D 查看/页面/上一页 pageup
查看/页面/下一页 pagedown 查看/页面/演示设置 Alt+:
查看/坐标轴 Alt+Q 查看/X光模式 T
查看/阴影 Alt+S 窗口/材质浏览器 Shift+X
窗口/场景信息 Shift+F1 窗口/图层 Shift+E
设计软件电脑图解-2
窗口/系统属性 Shift+P 窗口/页面设置 Alt+L
窗口/阴影设置 Shift+S 窗口/组建 Shift+C
工具/材质 X 工具/测量/辅助线 Alt+M
工具/尺寸标注 D 工具/量角器/辅助线 Alt+P
工具/路径跟随 Alt+F 工具/偏移 O
工具/剖面 Alt+/ 工具/删除 E
工具/设置坐标轴 Y 工具/缩放 S
工具/推拉 U 工具/文字标注 Alt+T
工具/旋转 Alt+R 工具/选择 Space
工具/移动 M 绘制/多边形 P
草图大师电脑图解-3
绘制/矩形 R 绘制/徒手画 F
绘制/圆弧 A 绘制/圆形 C
绘制/直线 L 文件/保存 Ctrl+S
文件/保存备份 Shift+N 文件/打开 Ctrl+O
文件/打印 Ctrl+P 文件/导出/模型 Ctrl+M
文件/导出/DWG/DXF Ctrl+D 文件/导出/图像 Ctrl+I
文件/另存为 Ctrl+Shift+S 文件/退出 Ctrl+W
文件/新建 Ctrl+N 物体内编辑/隐藏剩余模型 I
物体内编辑/隐藏相似组建 J 相机/标准视图/等角透视 F8
相机/标准视图/底视图 F3 相机/标准视图/顶视图 F2
相机/标准视图/后视图 F5 相机/标准视图/前视图 F4
相机/标准视图/右视图 F7 相机/标准视图/左视图 F6
设计软件电脑图解-4
相机/充满视图 Shift+Z 相机/窗口 Z
相机/漫游 W 相机/配置相机 Alt+C
相机/绕轴旋转 Alt+X 相机/上一次 TAB
相机/实时缩放 Alt+Z 相机/透视显示 V
渲染/材质贴图 Alt+4 渲染/单色 Alt+5
渲染/透明材质 K 渲染/线框 Alt+1
草图大师电脑图解-5
渲染/消影 Alt+2 渲染/着色 Alt+3
以上就是sketchup常用的快捷键说明了。
